1200 kVA Substation Transformer-13.8kV


  • Primary Voltage Ratings: 13.8 kV
  • Secondary Voltage Ratings: 240V
  • H.V. TAP RANGE: 13.8±2×2.5%
  • CONNECTION TYPE: Dyn11
  • TYPE: substation transformer
  • BIL: 30-90
  • Standards: IEEE C57
  • Application: Industry, Energy storage, BESS, EV charging, Utility, Crypto mining
  • Power Rating: 1200 kVA

Daelim Transformer successfully exported six sets of IEEE Standard 1200 kVA transformers to Venezuela. These transformers meet the stringent specifications of the IEEE standard, ensuring high-quality performance and reliability for their intended applications.


Quote Now

K-factor: K13
HV & LV  sealing cover
Sidewall-mounted bushings
Liquid insulant  Class B, Type I
IEEE standards C57.12.00 and C57.12.36
Aluminum winding conductors to optimize cost

Contact Daelim Transformer for special requirements

pocket base welded to tank
name plate ground pad on tank wall
radiators cable connection box,hv
handhole cable connection box,lv
tap changer tank and cover assembly
15kV HV bushing rigid barrier between hv&lv
1kV LV bushing liquid temperature indicator
pressure relief device drain valve with sampling device
liquid level indicator lifting hook for complete transformer
vacuum pressure guage lifting eye for active part with tank cover

Our skilled engineering team ensures the provision of comprehensive and accurate design drawings for your transformer within one week of placing the order.

Through our streamlined manufacturing processes, we commit to completing the production within 8-10 weeks, maintaining a strong emphasis on quality assurance.

After production, the shipping time may vary from 15 to 30 days depending on the destination region. Rest assured, we strive to ensure efficient transportation and timely delivery of your transformer.

1200 kVA Substation Transformer

1200 kVA Transformer Specifications

1200 kVA Transformer Specifications

The SL-1200 kVA-13.8 kV-0.24kV transformer is a three-phase unit with a power rating of 1200 kVA. It operates using the ONAN (Oil Natural Air Natural) cooling method, providing efficient cooling without the need for additional cooling equipment. The transformer has 5 tap positions for voltage adjustment.

The vector group of the transformer is Dyn11, which denotes the winding connections. The high-voltage (HV) side operates at 13800V, while the low-voltage (LV) side outputs at 240V.

The transformer exhibits a load loss of 14000W when operating at its rated voltage and a no-load loss of 1800W. With an efficiency of 99.18%, it demonstrates optimal power conversion efficiency.

The impedance of the transformer is 4.50%, indicating its ability to handle variations in load and provide stable voltage output. It is color-coded in ANSI 61- Gray.

Additionally, the transformer has a K-factor of K-13, representing its ability to handle harmonics and non-linear loads. This ensures reliable operation even in environments with high harmonic distortion.

Learn more about Substation Transformer

Send Inquiry Now

Transformer Dimension & Weight

The SL-1200 kVA-13.8 kV-0.24kV transformer has the following dimensions: Width*Length*Height: 2450mm*1850mm*1820mm.

The tank & accessories of the 1200kVA transformer weigh 1480kg. The total oil weight in the transformer is 990kg. Consequently, the total weight of the SL-1200 kVA-13.8 kV-0.24kV transformer is 4100kg. These weight specifications provide an understanding of the overall mass of the transformer, including the tank, accessories, and oil content.

Get Price
Transformer Dimension & Weight

1200 kVA Transformer

1200 kVA Transformer Assembly

1200 kVA Transformer Assembly

1200 kVA Transformer Drawing

1200 kVA Transformer Drawing

1200 kVA Transformer Package

1200 kVA Transformer Package
