Differences Between Copper Core and Aluminum Core Transformers

The primary difference between copper core and aluminum core transformers lies in the material of the coil. Both types have the same losses and power consumption, but their performance and suitability differ based on certain conditions:

Copper Core Transformer

  • Conductivity: Copper has better conductivity than aluminum.
  • Temperature Rise: Copper core transformers have a slower temperature rise compared to aluminum.
  • Load Capacity: Suitable for high-load applications (80% or higher).
  • Durability: Higher melting point and better performance under high load conditions.



Aluminum Core Transformer

  • Conductivity: Aluminum has lower conductivity compared to copper.
  • Temperature Rise: Aluminum core transformers heat up more quickly.
  • Load Capacity: Not ideal for high-load applications due to the lower melting point.
  • Economy: More cost-effective for applications with lower load requirements.


Recommendation

High Load: Choose a copper core transformer for better performance and reliability.
Low Load: Choose an aluminum core transformer for cost savings if the load is not high.


Daelim Transformer offers both copper core and aluminum core transformers. For further inquiries or assistance, please feel free to contact us.
